This flowmeter family features a stable, corrosion resistant housing made of SS 1.4301 [304 SS].
The quick and easy to handle Snap-In technology assures fast assembly and disassembly of the meter tube.
Flow ranges: min. 0.05 to max. 2300 cm3/min (water), min. 4.8 to max. 69200 cm3/min (air).
Borosilicate glass meter tube
Resistant to practically all fluids
Polycarbonate safety protection cap
Integrated needle valve in the in- or outlet
Alarms: Min., Max., min. and Max.
Rangeability: ≥10:1
Material: Stainless Steel, Brass
Scale design: % or direct reading scales,Dt/Df ratio scale, millimeters
Accuracy classes (VDE/VDI 3513) 5 in. Scale Length: 1/4in.& 1/8 in. Tube Diameter- Class 2.5, 1/16 in. Tube Diameter- Class 6,3 in. Scale Length: All sizes Class 10, 1-1/2 in. Scale Length: All sizes Class 10
Stainless steel fittings: 0 to 120°C Process
Brass fittings: 0 to 95 °C Process
Connections: 1/4 in. NPT or G1/4 internal thread, rear-facing horizontal or vertical
Body: 304 SS
Operator Protection Shield: Polycarbonate
Aeration
Gas sampling systems
Burner control
Level measurement
Purging applications
Nitrogen generators
Corrosive liquids
Food and beverage applications
FAM3200 (Series 10A3200)
