The AT600 Magnetostrictive Transmitter is based on the Same Magnetostrictive Principle as the AT100 Model.
The AT600 is a Compact Magnetostrictive Liquid Level Transmitter is Designed to Mount Externally on the KM26 Magnetic Level Gauge or other Magnetic Level Gauges.
Designed to Mount Externally to K-TEK KM26 or Other Magnetic Level Gauge
High Resolution 4-20 mA Output
Simple Mounting and installation
No Process Piping or Valve Required
Very Compact Design
Suitable for High Temperature Applications
Calibrates Without Opening Enclosure
Stainless Steel Enclosure
Repeatability: .01% of full scale or 0.030”, whichever is greater
Non-Linearity: 02% of full scale or .07”, whichever is greater
Mounting: Stainless steel clamps for KM26 chamber
Accuracy: .02% of full scale or .10”, whichever is greater
Loop Supply Voltage: 13.5 to 36 VDC
Housing type: Explosion Proof 316L Stainless Steel,with 1/2” FNPT Connection
Electrical Connection: 1/2” FNPT,M20 Optional
Reverse Polarity Protection: Diode in series with loop
Output/Communications: Standard 4-20 mA DC Calibration via magnets
Failsafe: Field Selectable: Upscale or Downscale
Operating Temperature: -40 to 450ºF (-40 to 232ºC) Ambient
Humidity: 0 to 100% R.H., non-condensing
Enclosure Rating: IP67
Oil and Gas Industries
Petrochemical Industries
Chemical Industries
Power Generation Industries
Water and wastewater treatment
Food and Beverage Industries
Pharmaceutical Industries
Pulp and Paper Industries
Biotech Industries
Marine Industries
