One AISI 316 insulated tank (300L) intended for preparation of cleaning solutions.
Option with an AISI 304 tank (500L) for the recovered water.
Hyginox SE pump (2.2kW).
AISI 316 collectors with manually operated butterfly valves.
AISI 304 frame with wheels.
Pressure gauge at the pump outlet.
Enclosed starter and pump protection.
Tested and verified in our test house
Cleaning of tanks of up to 3000L
Cleaing solution flow 10000 L/h
Cleaning solution pressure 2 bar
Parts in contact with the media: AISI 316
Other parts: AISI 304
Pump mechanical seal: C/SiC/EPDM
Gaskets: in contact with the product EPDM
Insulation: Rock wool
Cleaning of tanks of up to 3000L
Cleaing solution flow 10000 L/h
Cleaning solution pressure 2 bar
